LCM12864N 128x64 Dot Matrix LCD Module STN Blue 6800 Interface KS0107 Driver
The famous brands display we have
BOE: Large-scale production, AMOLED, all-size dominance. You could get BOE LCD Modules from us, or customize display here using BOE glass.
AUO: High-quality TFT displays, perfect for many automotive and industrial scenarios. You could share product drawing or part number with us, we will check for lead time and quotation for you.
Innolux: Both glass only or original displays are available here.
Tianma: Provide abundant solutions for industrial and custom displays.
Waveshare: It's embeded solutions integrator/ reseller.
E-paper displays: E-ink, Good display, DKE or other e-paper display brands.
If you are looking for more cost-effective or some products that are EOL, you could ask for recommendations, we will send you quotation and lead time based on your requirements.
Product Description
| Item | Description |
| Model | LCM12864N |
| Display Type | LCM |
| Resolution | 128 x 64 dots |
| Module Dimension | 75.0 x 52.7 x 8.9 mm |
| View Area | 60.0 x 32.6 mm |
| Dot Size | 0.4 x 0.4 mm |
| Dot Pitch | 0.43 x 0.43 mm |
| LCD Type | STN |
| Driver IC | KS0107 + KS0108 |
| Duty/Bias | 1/64 Duty, 1/9 Bias |
| View Direction | 6 O'clock |
| Logic Voltage | 4.7V - 5.3V |
| Logic Current | 0.9 mA |
| LCD Drive Voltage | 8.0V - 17.0V |
| Operating Temp | -20°C ~ +70°C |
| Storage Temp | -30°C ~ +80°C |
Short Description:
The LCM12864N is a 128x64 dot matrix graphic LCD module using STN blue film display technology with a 6 o'clock view direction. The module uses KS0107 or equivalent controller, supports 6800 series 8-bit MPU parallel interface, and integrates LED backlight.
